Arrow Mode
The direction of travel is shown by a simple arrow. When approaching a guidance point, such
as an intersection, the display switches to show the distance and direction to the guidance
point.
Mixed Mode
The map of your surroundings is shown on the left, and an arrow showing the direction of
travel is shown on the right.
Enlarged map of the intersection
When “Close-up of Junction” in the “Settings Menu” is on, an enlarged map of the junction
appears.
