Getting Ready

Name of Each Part

First, prepare the following items.

…

Wireless LAN converter (this unit)

…

LAN/USB feeder cable (supplied item)

* This is a cable which integrates LAN cable and USB feeder cable, which supplies power

without using an AC adapter. Be sure to use the supplied one.
The one end whose power cable is longer than the LAN cable is connected to the main unit
side, and the other end whose power cable is the same length as the LAN cable is connected
to AV receiver.

…

Start Guide (this document)

…

AV receiver, computer (prepare separately)

…

Environment that can be connected to the Internet (prepare separately)

1

2

3

5

4

6

Front

Back

Top

Side

1

POWER lamp

2

WLAN lamp

3

LAN lamp

4

Power port

5

LAN port

6

Reset/WPS button

Check Items for Setup

# If you do not use the Internet, you need to arrange for Internet access first.

# Do not connect the LAN/USB feeder cable via a USB hub, etc.
