Fig. 11C—Accessory Electric Heater Wiring
A05209
TABLE 6—ELECTRICAL DATA—564B
UNIT SIZE
564B
V-PH-HZ
VOLTAGE
RANGE
COMPRESSOR
OFM
FLA
IFM
FLA
ELECTRIC HEAT SINGLE POINT POWER SUPPLY
MIN MAX RLA LRA Nominal KW* FLA MCA
FUSE OR
CKT BKR
MOCP
024 208/230–1–60 187 253 10.9 54.0 0.9 4.1
—/—
3.8/5.0
7.5/10.0
5.4/7.2
—/—
18.1/20.8
36.1/41.7
26.0/30.0
18.6/18.6
41.2/44.7
63.8/70.7
51.1/56.1 25/25
30/35
60/60
40/45 —
—
—
—
030 208/230–1–60 187 253 13.5 72.5 0.9 4.1
—/—
3.8/5.0
7.5/10.0
11.3/15.0
5.4/7.2
—/—
18.1/20.8
36.1/41.7
54.2/62.5
26.0/30.0
21.8/21.8
44.4/47.9
57.0/73.9
89.5/100.0
54.3/59.3
30/30
30/35
60/60
—
40/45
—
—
—
80/90
—
036 208/230–1–60 187 253 17.5 88.0 1.5 6.0
—/—
3.8/5.0
7.5/10.0
11.3/15.0
5.4/7.2
—/—
18.1/20.8
36.1/41.7
54.2/62.5
26.0/30.0
29.4/29.4
52.0/55.4
74.5/81.5
97.1/107.5
61.9/66.9
35/35
35/35
60/60
—
40/45
—
—
—
80/90
—
042 208/230–1–60 187 253 19.4 104.0 1.5 6.0
—/—
3.8/5.0
7.5/10.0
11.3/15.0
15.0/20.0
5.4/7.2
—/—
18.1/20.8
36.1/41.7
54.2/62.5
72.2/83.3
26.0/30.0
31.7/31.7
54.3/57.8
76.9/83.8
99.4/109.9
122.0/135.9
63.2/69.2
40/40
40/40
60/60
—
—
40/45
—
—
—
80/90
100/125
—
048 208/230–1–60 187 253 24.7 116.0 1.5 7.7
—/—
3.8/5.0
7.5/10.0
11.3/15.0
15.0/20.0
5.4/7.2
—/—
18.1/20.8
36.1/41.7
54.2/62.5
72.2/83.3
26.0/30.0
40.0/40.0
62.6/66.1
85.1/92.1
107.7/118.1
130.3/144.2
72.5/77.5
50/50
50/50
—
—
—
50/50
—
—
60/70
80/90
100/125
—
060 208/230–1–60 187 253 28.0 118.0 3.0 7.7
—
3.8/5.0
7.5/10.0
11.3/15.0
15.0/20.0
5.4/7.2
—/—
18.1/20.8
36.1/41.7
54.2/62.5
72.2/83.3
26.0/30.0
45.7/45.7
68.2/71.7
90.8/97.8
113.4/123.8
135.9/149.9
78.2/83.2
60/60
60/60
60/60
—
—
60/60
—
—
—
80/90
100/125
—
FLA Full Load Amps
LRA Locked Rotor Amps
MCA Minimum Circuit Amps
MOCP Maximum Overcurrent Protection
RLA Rated Load Amps
NOTES:
1.
In compliance with NEC (National Electrical Code) requirements for multimotor and combination load equipment (refer to NEC Articles 430 and 440), the overcurrent
protective device for the unit shall be Power Supply fuse. The CGA (Canadian Gas Association) units may be fuse or circuit breaker.
2. Minimum wire size is based on 60 C copper wire. If other than 60 C wire is used, or if length exceeds wire length in table, determine size from NEC.
