Controls and displays
Remote control unit
VOL
FUNC
CALL
MEMO
BATTLE
RHYTHM
DJ MIX
EXIT
CUE
MENU
TOOLS
8 SKIP
8 SKIP
TEMPO
TEMPO
ENTER
STANDBY/ON
1
1
1
1
1
1
1
2
2
2
2
2
2
2
6
6
6
6
6
6
6
8
8
8
8
8
8
8
7
7
7
7
7
7
7
9
9
9
9
9
9
9
10
1
1
10
10
10
10
10
10
3
3
3
3
3
3
3
5
5
5
5
5
5
5
4
4
4
4
4
4
4
1 uSTANDBY/ON
Switches the unit between standby and on. (page 13)
2 TOOLS
Memory
USB
STEEZ
Configures settings such as the playback method of files for the selected
input function. (page 15, 20, 21)
3 abcd/ENTER
Used when configuring the settings.
! 8 SKIPo/p
Memory/USB/STEEZ
Fast forwards/rewinds the track being played by one-eighths (or
2/4/8-eighths). (page 22)
! TEMPO+/-
Memory/USB/STEEZ
Accelerates or slows down the track’s tempo. (page 22)
4 MENU
Sets various device options. (page 20, 21)
5 Playback control buttons
Memory
USB
STEEZ
iPod
In iPods, the operation follows the playback functions of the iPod.
! f
Starts/pauses playback.
! o
Goes back to the beginning of the track. Goes back to the begin-
ning of the previous track by pressing twice. Rewinds rapidly by
pressing and holding.
! p
Proceeds to the next track. Fast forwards by pressing and
holding.
6 Cue control buttons
Memory/USB/STEEZ
! CUE CALL
Moves to the position configured by the cue settings and plays
back. (page 22)
! CUE MEMO
By pressing the button during playback, a cue is placed at that
position.
7 FUNC
Use to change the input function. The source changes as below.
Memory
(internal memory)
d USB/STEEZ PORTABLE d iPod d
AUX IN
(external input)
d (Memory)
8 VOL+/-
Use to set the listening volume. (page 13)
9
Confirm and exit the current menu screen.
10 Playback mode buttons
! BATTLE
Memory/USB/STEEZ
Press to select Battle mode. (page 19)
! DJ MIX
Memory/USB/STEEZ
Press to select DJ Mix mode. (page 21)
! RHYTHM
Memory
Press to select Rhythm Machine mode. (page 21)
! EXIT
Closes the selected playback mode.
