Billion Electric Company 400G - Manual (Page 77)

Billion 400G Router
Chapter 4: Configuration
74
External Port: The Port number on the Remote/WAN side that is used when accessing the virtual server.
Redirect Port: The Port number that the Local server on the LAN network will be listening on.
Internal IP Address: The private IP, on the LAN network, of the virtual server application.
Lists all the existing computer connections on the network. You may assign a Computer by IP
address or MAC address from this list.
Select the Add button to apply your changes.
Example: List of some well-known and registered port numbers.
The Internet Assigned Numbers Authority (IANA) is the central coordinator for the assignment of unique
parameter values for Internet protocols. Port numbers range from 0 to 65535, but only ports numbers 0 to 1023 are
reserved for privileged services and are designated as “well-known ports” (Please refer to Table 5).Registered
ports are numbered from 1024 through 49151. The remaining ports, referred to as dynamic or private ports, are
numbered from 49152 through 65535.
For further information, please see IANA’s website at: http://www.iana.org/assignments/port-numbers
Table 5: Well-known and registered Ports
Port Number
Protocol Description
20 TCP FTP Data
21 TCP FTP Control
22 TCP & UDP SSH Remote Login Protocol
23 TCP Telnet
25 TCP SMTP (Simple Mail Transfer Protocol)
53 TCP & UDP DNS (Domain Name Server)
69 UDP TFTP (Trivial File Transfer Protocol)
80 TCP World Wide Web HTTP
110 TCP POP3 (Post Office Protocol Version 3)
119 TCP NEWS (Network News Transfer Protocol)
123 UDP NTP (Network Time Protocol) / SNTP (Simple Network Time
Protocol)
161 TCP SNMP
443 TCP & UDP HTTPS
1503 TCP T.120
1720 TCP H.323
4000 TCP ICQ
7070 UDP RealAudio
