Olympus PT-047 User Manual
Page 42
EN 12
En
Installation and removal of the LCD hood
Installation
Strongly push the mounting projections of the LCD hood as shown in the
figure into the guides above and below the LCD monitor window.
Removal
Remove the mounting projections of the LCD hood from the guides above
and below the LCD monitor window by widening the LCD hood.
Mounting and removing the lens cap
Fit the lens cap onto the lens ring as
shown in the figure. Be sure to
remove the lens cap before
shooting.
Guides
Installation
Removal
PT-047_EN.book Page 12 Tuesday, December 9, 2008 10:53 AM
