8. Tools Menu
Image 8-8
8.5 PiP layout
Overview
• PiP Save
• PiP rename layout
• PiP delete layout
8.5.1 PiP Save
What can be done ?
The active layout can be saved or "saved as".
When a new layout is saved it is added to the PiP select menu.
A fixed layout can be edited (re-sizing, re-positioning,...) but it can not be saved under its original name.
How to save a layout ?
1. Press MENU to activate the Tool bar
2. Press → to select the Tools item
3. Press ↓ to Pull down the Tools menu
4. Use ↑ or ↓ to select PiP layout
5. Press → to pull down the menu
6. Use ↑ or ↓ to select PiP save or save as (image 8-9)
7. Press ENTER
If save as has been selected, a dialog box is displayed (image 8-10)
Use ← or →, the numeric keys on the remote, or the keypad to enter the name and exit with BACK or MENU.
If save as has been selected, a message box is displayed (image 8-11)
Image 8-9
Image 8-10
Image 8-11
R5976491 IQ PRO G500 01/02/2007 79
