Warning, Four-wire connection – Alliance Laundry Systems H242I User Manual
Page 26
24
504509
Four-Wire Connection
D436IE2B
NEUTRAL
(WHITE
WIRE)
TERMINAL
BRACKET
GROUND
SCREW
WHITE
WIRES
TERMINAL
BLOCK
NEUTRAL
TERMINAL
“L1”
TERMINAL
BLACK
WIRE
GROUND
WIRE
POWER CORD -
NOT SUPPLIED
WITH DRYER
(FOUR-WIRE)
STRAIN
RELIEF
RED
WIRES
GROUND
WIRE
BLACK
WIRE
“L2”
TERMINAL
RED
WIRE
SLOTTED
HEX HEAD
SCREWS
(Shipped
inside
the dryer
or removed
in Step 2)
Dryer unit is shown with the access cover removed for illustration purposes only. To reduce the
risk of an electric shock, NEVER operate the dryer unit with the access cover removed.
W150
WARNING
