ATTO Technology Inc. iPBridge Installation and Operation Manual
3 Configure the iPBridge
To configure the ATTO iPBridge, use ATTO ExpressNAV. Default values are appropriate for most
configurations, but may be modified.The ExpressWizard provides one-button setup for many applications.
Default values are appropriate for most applications. If
you wish to change these values, use ATTO
ExpressNAV, a browser-based graphical interface.
Other methods are also available. Refer to
If you do not use the ExpressWizard, continue to
• Mapping and addressing, also known as
•
•
Preliminary steps
1
If you are not already in
the ExpressNAV
interface, type the IP
address of your
iPBridge in a standard
browser as found in
Using ExpressNAV
on
page 23, click Enter
Here, type in your user
name and password,
and click OK.
2
The Status page
appears.
You may view the
default settings by
clicking on each
element in the left hand
menu, then continue in
one of three ways:
• Review the settings, keeping the automatic
settings created when you powered up your
iPBridge and do nothing now.
• Use the ExpressWizard, accessed from the
side menu, to initially set up your iPBridge
and its attached storage for specific
applications automatically.
• Use the individual pages listed on the side
menu to make changes or use other features
as needed.
ExpressWizard
Most applications may be set up automatically
using the ExpressWizard from the ExpressNAV
interface. The ExpressWizard simplifies initial
configuration of the iPBridge
1
Follow the
.
2
From the side menu select ExpressWizard.
3
Select your storage type
• Digital video disk storage: optimized for
digital video (sequential access)
configurations
• Digital audio disk storage: optimized for
audio applications (sequential access)
• IT/database disk storage optimized for
general IT and database applications
(random access).
• Tape storage
• Optical storage
4
Click Next.
5
In the Devices Detected page, click on
Rescan to ensure all the devices you wish in
your storage configuration are present. The
ExpressWizard uses all attached storage for
the configuration.
6
When all devices are listed, click Next.
7
Data port IP address, subnet mask and
gateway information is listed. Change any
elements as needed.
