MAINTENANCE

Infrequent Lubrication as Required

■

Apply automotive type oil directly on slide tubes. It will

be picked up and dispersed by built in felt wicks.

■

Apply a light oil or a pressurized light spray oil to the

arm pivot shaft (47).

■

Apply a light oil or a pressurized light spray oil to the

torsion spring (46) as shown.

■

Apply a light oil or a pressurized light spray oil to the

lower guard spacer (44), roller (45) and cover plate (3)

as shown.

MOTOR BELT TENSION (FIG. 26)

The motor belt tension was properly adjusted at the

factory. However, to check the belt tension:

■

Use a Phillips screwdriver to remove the five screws

holding the belt cover and remove the cover.

■

To check the belt tension squeeze the belt. Using light

pressure the belt should deflect approximately

25.4 mm.

■

To adjust the tension:

- Use a Phillips screwdriver to loosen(but do not

remove) the six motormount screws.

- To increase the belt tension turn the adjusting

socket head set screw clockwise. To decrease the

tension turn the adjusting set screw counter-

clockwise.

Note: Excessive belt tension will cause the motor to

fail prematurely.

- Securely tighten the six motormount screws.

■

Replace the belt cover.

TROUBLESHOOTING GUIDE

General

Problem

Probable Cause

Suggested Corrective Action

Blade hits table

1. Misalignment

1. Get authorized Service

Angle of cut not accurate

1. Misalignment

1. See “Alignment” section

Can’t move miter adjustment

1. Sawdust under table

1. Vacuum or blow out dust

Wear Eye Protection

Power head wobbles

1. Loose pivot points

1. See Bevel Pivot Adjustment

in “Alignment” section

Power head won’t fully rise

1. Lubrication needed

1. See “Lubrication” section

or blade guard won’t fully close

2. Part failure

2. Get authorized Service

3. Pivot spring or guard spring

3. Get authorized Service

not replaced properly after service

4. Sawdust sticking to stops

4. Inspect/clean stops

Blade binds, jams, burns wood

1. Improper operation

1. See “Basic Saw Operation” section

Rough cuts

2. Dull blade

2. Replace or sharpen blade

3. Improper blade

3. Replace with 305mm diameter blade

designed for the material being cut

4. Bent blade – check flatness

4. Replace blade

across expansion slots on blade

Tool vibrates or shakes

1. Sawblade not round

1. Replace blade

2. Sawblade damaged

2. Replace blade

3. Sawblade loose

3. Tighten arbor screw

4. Other

4. Get authorized Service

Power head hard to

1. Lube needed

1. See - “Lubrication” section

pull/push down
