9
Step 6
A. Cylinder Guard Assembly
Attach Wire Guard to Front Crossbar and Back Panel with two 5/32 x .47” Bolts.
B. Cylinder Blocking Wire Assembly
Attach Cylinder Blocking Wire to Right Side Panel with one 5/32 x .47” Bolt and nut. Attach to Bottom Panel with one
5/32 x .47” Bolt.
To reduce the risk of serious bodily injury or death from fire or explosion:
• Never remove guards or devices to prevent storage of spare or oversize LP Gas Cylinders not recommended for
this grill.
WARNING
!
Step 7
Door Handle Assembly
Assemble Handle to Left Door using two 5/32 x .22” Bolts.
Repeat with Right Door.
Note: 2 extra screws provided.
5/32 x .22” Bolt set
4 pc
5/32 x .47” Bolt set
4 pc
5/32 Nut
1 pc
A
B
nut
Step 6C
Center Wheel Assembly (Model 6804)
Remove screws from Cabinet Bottom Panel.
Locate “Center Wheel” as shown and fasten in place to
Cabinet Bottom Panel with screws that were just removed.
