38
Parts List- Model 6804 Parts List- Model 6805
Key Description Quantity
1 Side Burner Cover 1
2 Side Burner Cooking Grid 1
3 Left Side Table 1
4 Side Burner Valve 1
5 Side Burner Knob Bezel 1
6 Control Knob 5
7 Side Burner 1
8 Ignition Box 1
9 Main Knob Bezel 4
10 Front Crossbar 1
11 Cylinder Wire guard 1
12 Cabinet Side Panel- LEFT 1
13 Cabinet Upright 1
14 Cylinder Retainer Bolt 1
15 Cabinet Bottom Panel 1
16 Cabinet Door- LEFT 1
17 Drawer Front 1
18 Drawer Box 1
19 Cabinet Door- RIGHT 1
20 Handle-Large Door 1
21 Handle-Small Door/Drawer 2
22 Hood Handle 1
23 Thermometer 1
24 Hood Bumper 2
25 Hood 1
26 Warming Rack 1
27 Main Cooking Grid 3
28 Flame Diffuser 4
29 Main Burner 4
30 Right Side Table 1
31 Tool Hooks 3
32 Electrode Assembly 2
33 Manifold Assembly 1
34 Control Panel 1
35 Bottom Panel 1
36 Cabinet Back Panel 1
37 Foil Pan 1
38 Grease Pan 1
39 Cabinet Side Panel- RIGHT 1
40 Cylinder Blocking Wire 1
41 Match Holder/Chain 1
42 Caster, Fixed 2
43 Caster, Locking Swivel 2
44 Manifold to SB valve Hose 1
45 Regulator 1
46 Center Wheel 1
47 Drawer Tracks 2
48 1/4-20 x .50” S/S Bolt 27
49 1/4-20 S/S Hex Nut 9
50 1/4-20 x .60” S/S Bolt 16
51 5/32 x .47” S/S Bolt 4
52 5/32 x .31” S/S Bolt 28
53 5/32 x .22” S/S Bolt 9
54 5/32 S/S Hex Nut 1
55 Side Burner Electrode 1 (no pic)
Key Description Quantity
1 Side Burner Cover 1
2 Main Burner 4
3 Side Burner Cooking Grid 1
4 Left Side Table 1
5 Side Burner Valve 1
6 Side Burner Knob Bezel 1
7 Control Knob 7
8 Infrared Side Burner 1
9 Manifold Assembly 1
10 Ignition Box 1
11 Control Panel 1
12 Main Knob Bezel 6
13 Front Crossbar 1
14 Cylinder Wire guard 1
15 Cabinet Side Panel- LEFT 1
16 Cabinet Upright 1
17 Cylinder Retainer Bolt 1
18 Cabinet Bottom Panel 1
19 Cabinet Door- LEFT 1
20 Cabinet Door- RIGHT 1
21 Handle, Door/Drawer 3
22 Hood Handle 1
23 Thermometer 1
24 Hood Bumper 2
25 Hood 1
26 Warming Rack 1
27 Main Cooking Grid 3
28 Flame Diffuser 4
29 Rotisserie Burner 1
30 Sear Burner 1
31 Right Side Table 1
32 Main Electrode Assembly 2
33 Tool Hooks 3
34 Bottom Panel 1
35 Foil Pan 1
36 Grease Pan 1
37 Cabinet Back Panel 1
38 Drawer Tracks 2
39 Cylinder Blocking Wire 1
40 Cabinet Side Panel- RIGHT 1
41 Match Holder/Chain 1
42 Drawer Body 1
43 Drawer Front 1
44 Caster, Fixed 2
45 Caster, Locking Swivel 2
46 Regulator 1
47 Center Wheel 1
48 1/4-20 x .50” S/S Bolt 28
49 1/4-20 S/S Hex Nut 10
50 1/4-20 x .60” S/S Bolt 16
51 5/32 x .47” S/S Bolt 4
52 5/32 x .31” S/S Bolt 29
53 5/32 x .22” S/S Bolt 9
54 5/32 S/S Hex Nut 1
55 Thermocouple -Side Burner 1 (no pic)
56 Thermocouple -Sear Burner 1 (no pic)
57 Thermocouple - Rotisserie 1 (no pic)
58 Side Burner Electrode 1 (no pic)
59 Sear Burner Electrode 1 (no pic)
60 Rotisserie Electrode 1 (no pic)
