MX28B200/400 –48 VDC User’s Manual (990-9133) Page 37
Control Unit Menu Structure
The complete menu structure shown in the order in which it is accessed from the control unit
display is presented in outline form below. Each indentation to the right represents a menu
level below the indicated title.
T o p L e v e l S e c o n d L e v e l T h i r d L e v e l F o u r t h L e v e l
MX28B200/400 +
STATUS ALARMS
Sys Voltage
•
Sys Current
•
Sys Temp
•
Batt Current
•
Batt Temp
MX28B200/400 +
US ALARMS SYSTEM
Alarm Item 1
•
Alarm Item 2
•
Alarm Item 3
• •
• •
• •
•
Alarm Item 14
•
Alarm Item 15
•
Alarm Item 16
MX28B200/400 +
MS SYSTEM MODULE SYS +
SET-ALM SETUP DA Sys HV Thr
• •
Sys HV Alm
• •
Sys LV Thr
• •
Sys LV Alm
• •
Rect Cfg Alm
• •
Rect 1ofN Alm
• •
Rect 2ofN Alm
• •
Sys HT Thr
• •
Sys HT Alm
• •
Sys LT Thr
• •
Sys LT Alm
• •
Hw Sys V Alm
• •
Hw Batt C Alm
