Punch options for Landscape jobs
Certain punch settings for Landscape jobs punch in the opposite side than you specify when
printing to the digital press from a FreeFlow client application.
To apply punch on Landscape jobs of all paper sizes correctly from FreeFlow applications,
send the job to the Fiery Hold queue and change the job’s Orientation to Landscape at the
Integrated Fiery Color Server before releasing to print. For details, see the following table.
FreeFlow Print Manager
Finishing punch settings Command WorkStation Job
Properties Finishing tab
punch settings Final output Punch Position
for Landscape jobs with
Orientation set to
Landscape
(Select Landscape for
Orientation from Command
WorkStation Job Properties)
Punch - Left Portrait Punch Position: Left
2 Hole punch Left 2 Hole punch
Punch - Right Portrait Punch Position: Right
2 Hole punch Right 2 Hole punch
Punch - Top Portrait Punch Position: Top
2 Hole punch Top 2 Hole punch
Coil Punch - Top Landscape
N OTE : To print a job as Coil
Punch-Top Landscape, you
must send the job from the
FreeFlow Print Manager to the
Fiery Hold queue.
Punch Position: Top
Advanced-LTR Punch
N OTE : Change the Punch
Position from Left to Top.
Top Coil Punch
Coil Punch - Bottom
Landscape
N OTE : To print a job as Coil
Punch-Bottom Landscape, you
must send the job from the
FreeFlow Print Manager to the
Fiery Hold queue.
Punch Position: Top
Advanced-LTR Punch
N OTE : Change the Punch
Position from Left to Top.
On the Layout tab, select the
Rotate 180 check box.
Bottom Coil Punch
