Video Accessories
Mounting boxes for Video Door Stations
Aiphone Communication Systems • 1700 130th Ave. N.E. • Bellevue, WA 98005
(425) 455-0510 • FAX: (425) 455-0071 • (800) 692-0200 • www.aiphone.com
Accessories
KAW-D 30 Degree Angle Box for Aiphone Video Door Stations
• For use with Aiphone models:
KA-DAR: Color Tilt camera
KB-BAR: Color Tilt camera
KC-DAR: Color Tilt camera
MK-DAC: B & W PanTilt camera
MK-DS: MK-Series fixed wide angle camera
SPECIFICATIONS:
Mounting: 1-gang box
Material: ABS Plastic
Color: Dark Charcoal Gray
Dimensions: 5-5/8”H x 4-1/8”W x 2-5/16”D
Surface Mounting Box for MK-DBC
• For use with Aiphone model:
MK-DBC PanTilt video door station
SPECIFICATIONS:
Mounting: 1-gang box
Material: ABS plastic
Color: Dark charcoal gray
Dimensions: 6-5/8”H x 4-3/16”W x 1-9/16”D
Surface Mounting Box for VY Entrance Stations
• For use with Aiphone models:
VY-5EM 5-call audio video entrance panel
VY-10EM 10-call audio video entrance panel
* B-VY-10 Cannot be used for entrance panels larger than 10 stations
SPECIFICATIONS:
Mounting: Wall mounted
Material: 1/16” steel
Color: Black
Dimensions: 11”H x 11-1/2”W x 2-1/2”D
- 85 -
MKW-R
B-VY-10
