29. Connect the boom connecting hose and the return
(bypass) hose to the "Y" valve fi tting, placing a hose
gasket in the swivel nut on each hose. Insert the return
hose into the top of tank. See fi gure 15.
FIGURE 15
CAUTION: Never allow negative pin on plug
to come in contact with positive "hot" post
on battery. Fire or explosion may result!
30. Hook up the wiring to the vehicle battery. Connect the
red wire on the fused wire harness to the positive post on
the battery or the "HOT" connection on a vehicle switch
or the ammeter. The brown wire may be grounded or
connected to the negative battery post. See fi gures 16
and 17.
IMPORTANT: Keep wiring away from hot engine parts,
rotating parts and pinch points.
IMPORTANT: Connect sprayer to 12 volt batteries only!
RETURN (BYPASS) HOSE
20
40 60
80
100 0
HOSE GASKET BOOM
CONNECTING
HOSE
HOSE GASKET
BROWN
RED
QUICK COUPLER
BATTERY
_
+ RED
BROWN
IN LINE SWITCH
PLUG
NEGATIVE PIN
12 VOLT TRACTOR BATTERY
POSITIVE
"HOT"
POST
+
_
NEGATIVE
POST
