Konica Minolta bizhub PRESS 2250P - Manual (Page 28)

Operator Manual STR0202 & SFM0704
DBCB-0512-0066-V005
STR0202 2-Side Trimmer & SFM0704 Square Fold Module
V005 RI01 23-04-2012 DBCB-0512-0066-V005 - 28 -
7. Technical information
Capabilities:
Electrical:
Compatibility: Standalone STR0202:
50Hz: 230/240V, 2.0A
60Hz: 230/240V, 2.0A
60Hz: 100/110/120/127V, 4.0A
(upon request, rewiring
required.)
Capacity: Up to 25 sheets
(80 g/m
2
, 100 pages booklet)
The 2-Side Trimmer should only be connected
to an approved electrical system which is rated
at a maximum of 16A and which is protected by
circuit breakers.
Physical:
Operational On Pallet in box
Height 1200 mm 1440 mm
Width 700 mm 760 mm
Depth 1510 mm 1410 mm
Weight ~208 Kg ~250 Kg
Booklet specifications
before trimming: trimmed:
Minimum booklet height: 204 mm 200 mm
Maximum booklet height: 340 mm 320 mm
Technical specifications
Speed (max.) 1800 booklets/hour
Trimmed size (min-max) 2mm - 35mm each side 4mm - 70mm together
Paper Weight (min-max) 60 g/m
2 - 300 g/m 2
A-symmetrical trim (min-max) ±15mm
Input / Output sheets Booklet Width (X) from 50 mm
up to 245 mm
Booklets Height (Z) 204 mm
up to 340 mm Note: Heights between 320
mm and 340 mm must be
trimmed back to 320mm or
shorter.
Booklet Staple Clearance from
top/bottom (minimal) 40mm
Noise Level (max) 70dB
