Aastra Telecom 6753I - Manual (Page 90)

82 Model 6753i IP Phone User Guide
Line Keys and Programmable Keys
Configuring Park/Pickup Keys
Use the following procedure to configure park/pickup on the 6753i phone.
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module .
Programmable Keys and Expansion Module Keys
2. Select from "Key 3" through "Key 6".
or
Select from “Key 1” through “Key 36” (M670i).
3. In the "Type" field, select Park for the first key. For the second key, select Pickup.
4. In the "Value" fields, enter the appropriate values based on the server in your network.
5. In the "Line" field, select the lines for which to apply the Park and pickup configuration.
Valid values are 1 through 9.
6. Click to save your changes.
Aastra Web UI
Note: Keys 1 and 2 (SAVE and DELETE keys) can be made configurable ONLY
by your System Administrator.
Note: For values to enter in this field, see the table “Park/Pickup Call Server
Configuration Values” on page 81 .
