56 MergePoint 5224/5240 Service Processor Manager User Guide
Viewing IPDU information
When a regular user or administrative user selects Access - IPDU - View IPDU Info, the View
IPDU Info screen appears.
Figure 3.18: View IPDU Info Screen
The following table shows the information displayed on the View IPDU Info screen for each IPDU.
You can view the following information underneath the name of each IPDU (under
Unit Information).
Table 3.3: Information on the View IPDU Info Screen
Field Description
Name Administrator - configured name or the default (s1), which is assigned to the
AUX port.
Number of units The number of IPDUs connected to the port. The first IPDU is referred to as the
master. Any other IPDUs daisy
- chained off the first IPDU are referred to as slaves.
Number of outlets Total number of outlets on all connected IPDUs.
Buzzer Whether a buzzer has been configured to sound when a specified alarm threshold
is exceeded.
Syslog Whether syslogging has been configured for messages from this IPDU.
Over current protection Whether over current protection is enabled (to prevent outlets from being turned on
if the current on the IPDU exceeds the specified threshold).
Table 3.4: IPDU Information Under Unit Information
Field Description
Model IPDU model number
