Lenovo IdeaCentre B520e User Manual
Page 27
Left and right views
The following illustrations show the location of connectors and components on the left and right sides
of the computer.
1. Memory card reader
4. Microphone connector
2. USB ports (2)
5. Optical drive
3. Headphone connector
6. TV buttons (Selected models only) Refer to Quick
Reference for detail instruction of Onekey TV buttons
Chapter 7
.
Locations
21
