5. Press the drive latch 1 and slide the optical drive out the front of the chassis.
Figure 35. Removing the optical drive
6. Remove the retainer bracket from the drive being replaced and install it on the new drive.
Figure 36. Retainer bracket for optical drive
7. Slide the new optical drive into the optical drive bay from the front until it snaps into position.
8. Connect the signal and power cables to the new drive.
9. Reinstall the front bezel.
10. Go to Chapter 4 “Completing the parts replacement” on page 45.
Replacing the diskette drive or card reader
Attention: Do not open your computer or attempt any repair before reading and understanding the “Important safety
information” in the ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the
ThinkStation Safety and Warranty Guide, go to:
http://support.lenovo.com
Chapter 3 . Installing options and replacing hardware 35
