8 User Manual
MARLIN 15" Color Display S5egSW15c
External Smart GPS Receiver & Video Input
EXPLORER 3 Controller for Color Display S5egSWctc
External Smart GPS Receiver
NOTE* New software name to run on internal GPS and external GPS hardware unit.
Software adjusts its behavior automatically depending on hardware detected
during start-up. New software versions use "XG" in software name, i.e.
S4XGSW5VC.This SW should be used instead of older S4EGSW5VC and
S4IGSW5VC.
MANUAL LAYOUT
♦
CHAPTER 1: Overview
Introduction to the basic information on the Fish Finder, its features
and use.
♦
CHAPTER 2: Fish Finder
Helps you understand how the chart plotter is connected to the Fish
Finder and how to operate to improve your fishing.
♦ ♦ ♦ ♦ ♦
CHAPTER 3: Setup your Fish Finder
Description of the Fish Finder Setup menu.
♦ ♦ ♦ ♦ ♦
CHAPTER 4: BB 50/200
Technical specification, dimension and installation of the BB 50/200
and set up of the hardware configuration.
♦ ♦ ♦ ♦ ♦
CHAPTER 5: Transducers
Introduction to the basic information on the transducer (device that
transmits and receives sound waves into the water).
♦ ♦ ♦ ♦ ♦
CHAPTER 6: Frequently Asked Questions
The Analytical Index is at the end of this User Manual.
IF YOU NEED ASSISTANCE
If your chart plotter does not operate properly, please refer to the chart plotter
User Manual.
