About this User Manual

INTRODUCTION

The chart plotter combined with the sonar performance of the Fish Finder is one

of the most advanced marine navigation system available.

Please read carefully this User Manual to learn the operating features for your

unit. Refer to your chart plotter User Manual for all other unit operating instructions.

CONVENTIONS USED

Throughout this User Manual, the labelled keys are shown in capital letters enclosed

in square brackets, for example [ENTER]; the software keys are shown in small

capital letters enclosed in square brackets, for example [E

DIT

Menu operations are in bold characters listed by keys sequence with the menu

names enclosed between inverted commas, for example [MENU] + "ALARMS"

+ [ENTER] means: press the [MENU] key, using the cursor key select the Alarms

menu and then press [ENTER].

Any menu operation and functions activation in this User Manual is related to the

following chart plotter models (see the following table). Whenever it is necessary,

a note has been inserted for those models with operational differences.

CHART PLOTTER NAME

DESCRIPTION

SOFTWARE

SW500e

5" Sunlight Readable Color Display

S4x2SW5vc

External Smart GPS Receiver

SW500i

5" Sunlight Readable Color Display

S4x2SW5vc

Internal GPS Receiver

SEAHORSE E

5" Sunlight Readable Color Display

S4xgSW5vc*

External Smart GPS Receiver

SEAHORSE

5" Sunlight Readable Color Display

S4xgSW5vc*

Internal GPS Receiver

BARRACUDA
