4. BB 50/200
This chapter provides instructions to assist in planning the installation of the
BB 50/200.
4.1 TECHNICAL SPECIFICATIONS
♦
Display Colors : 16 colors
♦
Display Vertical Resolution : up to 400 pixels (depending on chart
plotter screen resolution)
♦
Power Requirements : 10 - 35 Volt dc
♦
Over Voltage protection
♦
Reverse Polarity protection
♦
Power Consumption - operating:17W max
♦
Power Consumption - stand by : 1.7W max
♦
Operating Frequency : Dual 50 and 200kHz
♦
Output Power : 600/1000W (4000/8000Wpp)
♦
Depth Range*
1KW/200kHz : 2.5Ft (0.76m) to 1200Ft (366m)
Max Typical = 980Ft (299m)
1KW/50kHz :
5Ft (1.52m) to 4000Ft (1219m)
Max Typical = 2700Ft (823m)
600W/200kHz :
2.5Ft (0.76m) to
700Ft (213m)
Max Typical = 600 Ft (183m)
600W/50kHz : 5Ft (1.52m) to 1500Ft (457m)
Max Typical = 1350 Ft (411m)
NOTE* This is not a guaranteed specification. The actual maximum depth capability
of the system depends on the type of transducer fitted, the reflectivity of the
bottom, water condition, etc.
♦
Status LED
♦
External Buzzer : 12VDC, 400mA
♦
Speed Sensor : if available on transducer
♦
Temperature Sensor : one channel TEMP1 (if available on
transducer), optional second channel
TEMP2
♦
NMEA Output sentences : Depth: $SDDPT, $SDDBT
Speed: $VWVHW
Trip Log: $VWVLW
Water Temperature: $YXMTW
TEMP2 Temperature: $YXXDR
♦
Operating temperature range : 0°C to +50°C
♦
Storage temperature range : -20°C to +70°C
♦
Weight : 1 kg (2,20 LBS)
♦
Water Proof Specification : IP 54
♦
Case Size : 7.73" (196.4mm) x 6.5"(164.96mm)
x 1.96" (50mm)
When the package containing the BB 50/200 is first opened, please check it for
the following contents (if any parts are missing contact the dealer the BB 50/200
was purchased from):
