4.7 SUGGESTED PLOTTER CONNECTIONS
The following are suggested "Fish Finder - chart plotter" connections.
WIRE COLOR FUNCTION
BBFF TX+
BBFF RX+
BBFF GND
BROWN
GRAY
BLACK
BBFF PLOTTER CABLE
QUICK DISCONNECT BRACKET CABLE
WIRE COLOR FUNCTION
RED
BLACK
WHITE
GREEN
YELLOW
BROWN
GRAY
ORANGE
PINK
BLU +10-35 Vdc
GND/COMMON
INPUT 1+
GND
OUTPUT 1+
INPUT 2+
OUTPUT 2+
INPUT 3+
OUTPUT 3+
GND
Fig.4.7 - Connection to the Fish Finder for chart plotter with quick disconnect bracket
If the chart plotter has a 8 pin Power & I/O connector see the following picture:
Chart Plotter
F
ema
le8P
in
Power &
I/O cable
of
Chart Plotter
Ma
le8P
in
POWER & I/O
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
X
X
POWER & I/O CONNECTOR
GND/COMMON
PWR+ (10-35 Vdc)
INPUT 1+
COMMON
OUTPUT 2+
OUTPUT 1+
INPUT 2+
OUTPUT EXTERNAL ALARM+ BLACK
RED
WHITE
GREEN
GREY
YELLOW
BROWN
BLUE
PIN
1
2
3
4
5
6
7
8
WIRE COLOR FUNCTION
BROWN
GRAY
BLACK
CABLE COLOR FUNCTION
BBFF Plotter Cable
FF TX+
FF RX+
FF GND
Fig.4.7a - Connection to the Fish Finder for chart plotter with 8 pin Power & I/O connector
Only for the SEAWAVE 3 chart plotter see the following picture:
POWER & I/O
POWER & I/O CONNECTOR
PIN
1
2
3
4
5
6
7
8
WIRE COLOR FUNCTION
GRAY
BROWN
BLACK
WIRE COLOR FUNCTION
BBFF PLOTTER CABLE
BBFF RX+
BBFF TX+
BBFF GND
BLACK GND/COMMON
RED PWR+ (10-35 Vdc)
WHITE INPUT1+
GREEN GND
GREY NOT CONNECTED
YELLOW OUTPUT1+
BROWN GND
BLU OUTPUT EXTERNAL ALARM+
Fig.4.7b - Connection to the Fish Finder for SEAWAVE 3 chart plotter
