V6 Syringe Drive Pump
PDS-0005 REV 7 4/13
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
© Norgren Kloehn, Inc. 2012
Ancillary items:
Communication cable RS485, 6" long; pump to pump (2 units) P/N 17736
Cooling Fan Option P/N 24290
Starter Kit (includes all items listed below) P/N 23427
24VDC Power supply P/N 23429
Adapter (card edge to AMP connectors) P/N 23428
Connector (card edge with solder pins) P/N 26875
Software; operator’s manual; and application notes. P/N 23422
Communications cable (RS232 / 5’ long; pump to computer) P/N 17734
Software support:
KloehnControl (configuration and debug program)
KSerial (command-line communication utility)
KCom (machine language helper program)
KProbe (communication trouble shooting utility)
Valves:
Configuration Orifice Distribution non-distribution Port Thread
Through mtg block 0.059 19218 — ¼-28 UNF
2-WAY 0.059 — — ¼-28 UNF
3-WAY 0.059 17616 17615 ¼-28 UNF
4-WAY 0.059 17617 17712 ¼-28 UNF
5-WAY 0.059 17618 — ¼-28 UNF
6-WAY 0.059 17619 — ¼-28 UNF
8-WAY 0.059 17620 — ¼-28 UNF
12-way 0.040 24105 — ¼-28 UNF
3-WAY 0.076 18189 18192 ¼-28 UNF
4-WAY 0.076 18190 18191 ¼-28 UNF
5-WAY 0.076 18188 — ¼-28 UNF
6-WAY 0.076 18193 — ¼-28 UNF
8-WAY 0.076 17877 — ¼-28 UNF
Valve construction:
V6 pump uses the same valves as the 50300 pump
Valve wetted surfaces have a Kel-F body insert and PTFE (Teflon) plug.
Port connection is 1/4-28 UNF.
Some valve ports may not be accessible when used with certain syringes sizes. See Application Notes for further information.
Standard Syringe Assembley (individually boxed):
Size Orifice Standard Syringe ZDV Port Thread
25ul 0.027 17591 — ¼-28 UNF
50ul 0.024 17592 — ¼-28 UNF
100ul 0.032 17593 — ¼-28 UNF
250ul 0.039 17594 19509 ¼-28 UNF
500ul 0.076 17595 19537 ¼-28 UNF
1.0ml 0.076 17596 25429 ¼-28 UNF
1.25ml 0.076 17597 25431 ¼-28 UNF
2.5ml 0.076 17598 19539 ¼-28 UNF
5.0ml 0.076 17599 18463 ¼-28 UNF
10.0ml 0.076 17600 18469 ¼-28 UNF
25.0ml 0.076 17601 23734 ¼-28 UNF
50.0ml 0.076 17602 — ¼-28 UNF
Syringe construction:
Syringes have Borosilicate glass. The 25ul, 50ul, and 100ul syringes use a standard plunger tip, while the 250ul through
50ml incorporate a canted spring design.
