Warning
Improper selection, misuse, age or malfunction of components used in
commercial vehicle systems can cause failure in various modes. The system
designer is warned to consider the failure modes of all component parts
used in commercial vehicle systems and to provide adequate safeguards to
prevent personal injury or damage to equipment or property in the event of
such failure modes. System designers and end users are cautioned to consult
instruction sheets and specifications available from the factory. The system
designer/end user is responsible for verifying that all requirements for the
application are met.
Warranty
The products described herein are warranted subject to seller’s Standard
Terms and Condition of Sale, available at seller’s website.
1.00
1.62
NUT & WASHER
1-1/8
1/2
1/8-27
NPTF THDS
IN
1-7/16
1-5/32
PULL PUSH
5/8-18 UNF THD
0.75
3/8
OUT
1-5/32
NUT AND
LOCK WASHER
1-1/8
KNOB
1-3/8
1.0
3/8
3/8
1/2
1/8 NPTF
TYP
PULL PUSH
INLET
OUTLET
2-9/16
5/8-18 UNF THD
1-0
1-25/32
55° ±5° INFLATE DEFLATE
DELIVERY
SEE DETAIL 1
BRASS BARB ACCEPTS
1/4" DOT TUBE 2PL
SUPPLY
2-3/16±1/16
1-5/8
5/16
1/4
DETAIL PANEL HOLE
SCALE 1
1.610 ±0.010
0.890 ±0.010
R 0.063 MAX.
1-3/8
3/8
3/8
PULL PUSH
5/8-18 UNF THD
1-3/4
INLET
1/8 NPTF
OUTLET
1/8 NPTF
1/2
1-5/32
NUT AND
LOCK WASHER
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document.
© Norgren GT Development Corporaton, 2014
Height Control and Lumbar Seat Valve
Dimensions (Inches)
Rev. 9/14 02
134-4 251-12B
251-12A 3013-4
