V07
● Compact design
● Low torque, non-rising adjusting knob
● Helps protect air operated equipment from over
pressure by retarding excessive pressure build up
● Snap action knob locks pressure setting when
pushed in
● Can be factory preset
● Can be disassembled without the use of tools or
removal from the air line
07 Series Pressure Relief Valve
1/8" and 1/4" Port Sizes
ALE-14-2
See Section ALE-24 for Accessories
Alternative Models
Port Size Substitute
1/8" 1
1/4" 2
Threads Substitute
PTF A
ISO Rc taper B
ISO G parallel G
Port Size Model Number Weight lbs (kg)
1/8" V07-100-NNKA 0.28 (0.13)
1/4" V07-200-NNKA 0.28 (0.13)
Ordering information. Models listed include PTF threads and 5 to 100 psig (0.3 to 7 bar) relief pressure adjustment range.
Option Substitute
Not applicable 0
Relief Pressure Adjustment Ranges Substitute
1 to 10 psig (0.1 to 0.7 bar) A
5 to 50 psig (0.3 to 3.5 bar) E
5 to 100 psig (0.3 to 7 bar) K
5 to 125 psig (0.3 to 8.6 bar) L
5 to 150 psig (0.3 to 10 bar) M
Option Substitute
Not applicable 0
Gauges Substitute
With G
Without N
Factory Preset Relief Pressure Substitute
Not factory preset N
Factory set, non adjustable relief P
pressure. Also specify desired
relief pressure on order.
- ★ ★ ★ ★ ★ ★ - 0 ★ V 7
ISO Symbol
