ALE- 63
Typical Performance Characteristics
RANGE: 10 to 232 psi (0.7 to 16 bar)
FLOW CHARACTERISTICS
0 20 40 60 80 100 dm 3 /s
AIR FLOW
0 40 80 120 160 200 240 scfm
8
6
4
2
0
OUTLET PRESSURE
bar g psig PORT SIZE: 1/2"
INLET PRESSURE: 150 psig (10 bar)
RANGE: 10 to 125 psig (0.7 to 8.6 bar)
100
80
60
40
20
0
120
FLOW CHARACTERISTICS
0 50 100 150 200 250 300 dm 3 /s
AIR FLOW
0 100 200 300 400 500 600 700 scfm
8
6
4
2
0
bar g
100
80
60
40
20
0
psig
PORT SIZE: 1-1/4"
INLET PRESSURE: 150 psig (10 bar)
RANGE: 10 to 125 psig (0.7 to 8.6 bar)
RELIEF FLOW CHARACTERISTICS
0 10 20 30 40 50 dm 3 /s
AIR FLOW
0 20 40 60 80 100 120 scfm
OUTLET PRESSURE
8
6
4
2
0
bar g
100
80
60
40
20
0
psig
TYPICAL ALL MODELS
INLET PRESSURE: 200 psig (14 bar g)
Service Kits
Item Type Part number
Service kit 1⁄4, 3⁄8, 1⁄2 5292-52
Service kit 3⁄4, 1, 1-1⁄4 5292-53
Service kits include seals, main valve and spring.
3.58 (91)
5.37 (136)
3.65 (93)
2.91 (74)
3.42 (87)
4.83 (123)
2.70 (69)
2.15 (55)
Panel mounting hole diameter: 1.26" (32 mm)
Maximum panel thickness: 0 to 0.12" (3 mm)
R24 Micro Trol Pressure Regulator
1/4" to 1-1/4" ports
Dimensions in inches (mm)
