PTH Filter/Regulator-Lubricator Combination Units
07 Series
1
.6
8
(4
3
)
1
.2
6
(3
2
)
2
.1
3
(5
4
)
1.50 (38)
1.78 (45) 1.78 (45)
3.55 (90)
1
.5
0
(3
8
)
0.174††
(4)
Dia.
0.29
(7)
Dia.
0
.5
5
(1
4
)
1
.1
2
(2
8
)
2
.6
7
(6
8
)
3
.7
2
(9
4
)
A
u
to
m
a
ti
c
D
ra
in
0
.3
8
(1
0
)
3
.8
7
(9
8
)
M
a
n
u
a
l
D
ra
in
1
.6
5
(4
2
)
3
.0
7
(7
8
)
W
it
h
o
u
t
D
ra
in
8
.3
1
(2
1
1
)†
0
.5
5
(1
4
)
†Minimum distance required to remove bowl
†† Mounting holes
All Dimensions in Inches (mm)
Alternative Models
P T H - ˙ ˙ ˙ - ˙ ˙ ˙ A
Lubricator Reservoir Substitute
Transparent with drain A
Metal with drain M
Filter/Regulator Drain Substitute
Automatic A
Manual M
Filter/Regulator Element Substitute
5 µm 1
40 µm 3
* Outlet pressure can be adjusted to pressures in excess of, and less than, those specified. Do not use these units to
control pressures outside of the specified ranges.
Port Size Substitute
1/8" 1
1/4" 2
Outlet Pressure
Filter/Regulator Adjustment Range* Relief
Bowl bar psig Type Gauge Substitute
Transparent 5 to 100 0.3 to 7 Relieving With 00
Transparent 5 to 100 0.3 to 7 Relieving Without 01
Metal / no sight glass 5 to 100 0.3 to 7 Relieving With 40
Metal / no sight glass 5 to 100 0.3 to 7 Relieving Without 41
Service Kits
Item Type Part number
Service kits, relieving, 5 µm element 3820-02
filter/regulator non relieving, 5 µm element 3820-01
Service kit, lubricator 3795-03
Replacement drains Manual 773-03
Automatic 3654-02
Replacement wall Integral 2 piece 6700-30
bracket for PTH unit
Filter/regulator service kit contains slip ring, diaphragm, valve seat with o-ring, valve, valve
spring, element, element gasket, and bowl o-ring.
Lubricator service kit contains sight-feed dome seal, cartridge o-ring, and bowl o-ring.
