PSC- 19
VP50
Proportional Pressure Control Valve
1
2 3
4
5
1 +24V d.c. supply
2 0-10 full range
3 Control signal (+ve)
4 Common (DC supply, signal and feedback return)
5 Chassis (earth)
Instrument pin configuration
0 7 14 21 28 35 42 49 56
(200) (400) (600) (800) (1000) (1200) (1400) (1600)
Flow in SCFM (Nl/min)
Forward Flow Characteristics
Supply Pressure 160 psig (11bar)
Outlet Pressure in psig (bar)
145
131
115
102
87
73
58
44
29
15
0
(10)
(9)
(8)
(7)
(6)
(5)
(4)
(3)
(2)
(1)
(-2000) (-1500) (-1000) (-500)
Relief Flow Characteristics
Supply Pressure 131 psig (9 bar)
Flow SCFM (Nl/min)
(9)
(8)
(7)
(6)
(5)
(4)
(3)
(2)
(1)
0
Outlet Pressure in psig (bar)
131
116
102
87
73
58
44
29
15
0
-70 -53 -35 -18 0
Characteristic Curves
2.15 (55)
3.85 (98) .28 (7)
1.10 (28) 1.97 (50)
.75 (19)
1.89 (48)
2.13 (54)
.97 (25) .83 (21)
1.42 (36)
.28 (7) .43 (11)
1.38 (35)
.28 (7)
Accessories
Designation Specification Type
Connectors with cable M12 x 1.5 pin; 16 ft (5m) 5 x 0.34 mm2 0250081
M12 x 1.5 pin; 30 ft (10 m) 5 x 0.34 mm2 0250472
Manifold Mounting Kit Interface plate, gasket, mounting screws 53ZZ5M00
NOTE: Refer to website to select an ISO 2 size base and accessories.
Dimensions in inches (mm)
