MS-9642 Mainboard

4-20

SMBus Resource Allocation

ISA Interrupt Allocation

ISA DMA Channel Allocation

SMBus Resource Allocation
Device

Address

Description

MS-7

0101 111X MSI ACPI Controller

DIMM Slot 1010 0000 SPD

IRQ

Description

IRQ0

System Timer

IRQ1

Keyboard Controller

IRQ2

Second 8259A

IRQ3

COM2 / COM4

IRQ4

COM1 / COM3

IRQ5

LPT2

IRQ6

Floppy Disk Drive

IRQ7

LPT1

IRQ8

RTC

IRQ9

Redirected IRQ2

IRQ10

Reserved

IRQ11

Reserved

IRQ12

Reserved

IRQ13

Math Coprocessor

IRQ14

Fixed Disk

IRQ15

Reserved
