MS-9642 Mainboard
4-4
Award POST Code
Award BIOS Error Message and Check Point (POST code) List (Need to be
modified, TBD)
· Error/Process Message.
# Short Name Description Possible FRUS
1 CMOS
checksum error
- Defaults
loaded Checksum of CMOS is incorrect, so the
system loads the default equipment
configuration. A checksum error may
indicate that CMOS has become corrupt.
This error may have been caused by a
weak battery. Check the battery and
replace if necessary. System board
2 CPU at nnnn Displays the running speed of the CPU. processor
3 Press ESC to
skip memory
test The user may press Esc to skip the full
memory test. System board
4 Floppy disk(s)
fail Cannot find or initialize the floppy drive
controller or the drive. Make sure the
controller is installed correctly. If no floppy
drives are installed, be sure the Diskette
Drive selection in Setup is set to NONE or
AUTO. system board
5 HARD DISK
initializing
Please wait a
moment
Some hard drives require extra time to
initialize. System board
6 HARD DISK
INSTALL
FAILURE Cannot find or initialize the hard drive controller
or the drive. Make sure the controller is
installed correctly. If no hard drives are
installed, be sure the Hard Drive selection in
Setup is set to NONE. System board
7 Keyboard error
or no keyboard
present Cannot initialize the keyboard. Make sure
the keyboard is attached correctly and no
keys are pressed during POST. To
purposely configure the system without a
keyboard, set the error halt condition in
Setup to HALT ON ALL, BUT KEYBOARD.
The BIOS then ignores the missing
keyboard during POST. System board
8 Memory Test: This message displays during a full
memory test, counting down the memory
areas being tested. DIMM
System board
