MSI Fuzzy 945GME2 V4.0 User Manual

Page 48

3-12

MS-9642 Mainboard

operating system that does not support or have any USB driver installed,
such as DOS and SCO Unix.

Azalia/AC97 Audio Select

Azalia is the codename of

“High Definition Audio.” This setting controls the

High Definition Audio interface integrated in the Southbridge.

Audio Amplifier Control

This setting disables/enables the audio amplifier.

Amplifier dB

When the

Audio Amplifier Control is set to [Enabled], users may adjust

the amplifier dB range between the lowest useful output and the largest
useful output level.

Onboard Ethernet #1/ #2/ #3

These settings disable/enable the onboard Ethernet controller.

Onboard LAN1/ LAN2/ LAN3 Boot ROM

The items enable or disable the initialization of the onboard LAN Boot ROMs
during bootup. Selecting [Disabled] will speed up the boot process.
