2-16
Hardware Setup
▍
MS-96D2
Hardware Setup
▍
MS-96D2
J
uMper
Clear CMOS Jumper: J_CMOS1
There s a CMOS RAM onboard that has a power supply from an external battery
to keep the data of system configuration. With the CMOS RAM, the system can
automatcally boot OS every tme t s turned on. If you want to clear the system
configuration, set the jumper to clear data.
Important
You can clear CMOS by shorting 2-3 pin while the system is off. Then return to
1-2 pin position. Avoid clearing the CMOS while the system is on; it will damage
the mainboard.
VGA Control Jumper: J_VGA1
Ths jumper s used to enable or dsable the VGA controller.
Clear Data Keep Data J_CMOS1
1
1 1
Dsable Enable J_VGA1
1 1 1
BIOS Recovery Jumper: J3
Users can short connect pn#2-3 to recover the system BIOS. When the system
s done wth the job, the buzzer wll beep to remnd users to set the jumper to ts
normal state (pn#1-2 short connected).
Normal
1
Recovery
1
J3
1
