Overview

▍

MS-96D2

1-3

Overview

▍

MS-96D2

4 USB 2.0 connectors

6 SATAII connectors

1 Power SMBUS connector (Optional)

1 IPMB connector (Optional)

1 Front Panel pinheader

1 SPI Flash ROM pinheader (for debugging)

1 Clear CMOS jumper

1 Chassis Intrusion connector

1 TPM Module connector

1 Front Panel ID pinheader

1 Recovery jumper

Slot

1 PCI-Express x16 slot

1 PCI-Express x8 slot (with x4 signal)

2 PCI slots, support 3.3V/ 5V PCI bus Interface

Dimension

243mm x 243mm

Mounting

8 mounting holes

System Management

SMBus (I2C)

Temperature, voltage and fan monitors

Power Management Features

ACPI 2.0

APM 1.2

-

-

-

-

-

-

-

-

-

-

-

■

■

■

■

■

■

■

■

■
