Front Panel Connector: JFP1
These are propretary front panel connectors that provde I2C bus connecton,
seral sgnal connecton, and electrcal connecton to the front panel swtches/
LEDs.
16
15
2
1
2
1
14
13
TPM Connector: JTPM1
Ths connector connects to an optonal TPM (Trusted Platform Module). Please
refer to the TPM securty platform manual for more detals.
PIN SIGNAL PIN SIGNAL
1
3
5
7
9
11
13
15 HDD+
HDD-
GND
SYS_RST_N
NC
FP_ID_LED_N
P3V3_AUX
P3V3_AUX 2
4
6
8
10
12
14
16 PLED
SLED
PWR_BTN_N
GND
NC
SYS_FLT_LED
LED2_ACT#_82578DM
LED2_ACT#_82574L
PIN SIGNAL PIN SIGNAL
1
3
5
7
9
11
13 CLK_33M_TPM
PLT_RESET_TPM#
LPC_AD0
LPC_AD1
LPC_AD2
LPC_AD3
LPC_FRAME# 2
4
6
8
10
12
14 P3V3_AUX
P3V3
PCH_SERIRQ
P5V
NC
GND
GND
