MSI MS-96D2 User Manual
Page 27
Hardware Setup
▍
MS-96D2
2-13
Hardware Setup
▍
MS-96D2
Serial ATA Connector: SATA0 ~ SATA5
Ths connector s a hgh-speed Seral ATA nterface port. Each connector can
connect to one Seral ATA devce.
Important
Please do not fold the Serial ATA cable into 90-degree angle. Otherwise, data
loss may occur during transmission.
SATA2
SATA3
SATA4
SATA5
SATA1
SATA0
