7
IN-Q431-09A
Q PUMP HEAD MODULE - PARTS PRICE LIST
PUMP HEAD REPAIR SERVICE
Should your FMI PUMP or PUMP SUBASSEMBLY need repairs, you should first contact the Customer Service
Department for a SERVICE SAFETY ASSURANCE FORM and a RETURN AUTHORIZATION NUMBER, you
may then ship it to us post-paid. You will be charged a flat service fee for each Pump Head Module returned plus
the cost of parts used and the postage required to return it to you. The Pump Head Module service fee includes
inspection, clean and test to agreed specifications and the replacement of Lip Seals and Gland Washer.
After examining a returned pump or subassembly by FMI Service Department, you will be requested to approve
the charges before repair work is started.
PARTS ORDERS
MINIMUM ORDER APPLIES FOR DOMESTIC or FOREIGN (Invoice price exclusive of shipping)
SHIPPING
Parts and repair orders will be shipped via United Parcel Service or U.S. Postal Service unless other
means are specified.
ALL PRICES ARE QUOTED IN U.S. DOLLARS, FOB SYOSSET, NY - Subject to change without no-
tice.
For Additional Information Call - Toll Free 800-223-3388 or email us at: [email protected]
* CERAMIC PISTONS & CYLINDER LINERS SOLD AS SETS ONLY
PART NO. DESCRIPTION
Q410-2 CARRIER
Q410-3 CARRIER STAINLESS STEEL
Q665 SPACER
R405-S CYL CASE, STAINLESS STEEL
R405-1S CYL CASE, SS, TEMP GLAND
R405-SAN CYL CASE, SANITARY STAINLESS STEEL
R405-SG
CYL CASE, SS ISOLATION GLAND
R406-K GLAND NUT, FLUOROCARBON
R406-0K GLAND NUT, FLUOROCARBON 1/8” PISTON
R406-1K GLAND NUT, FLUOROCARBON 1/4” PISTON
R406-2K GLAND NUT, FLUOROCARBON 3/8” PISTON
R406-3K GLAND NUT FLUOROCARBON
R406-S CYLINDER NUT R405-S, R405-SAN
R407-0 CYLINDER LINER
R407-1 CYLINDER LINER
R407-2 CYLINDER LINER
R407-1C* CYLINDER LINER
R407-2C* CYLINDER LINER
R407-3C* CYLINDER LINER
R408-1A LIP SEAL, RULON AR 1/4”
R408-2A LIP SEAL, RULON AR 3/8”
R408-0J LIP SEAL, RULON J 1/8”
R408-1J LIP SEAL, RULON J 1/4”
R408-2J LIP SEAL, RULON J 3/8”
R408-1T LIP SEAL, TEFLON 1/4”
R408-2T LIP SEAL, TEFLON 3/8”
R408-3A LIP SEAL, RULON AR 1/2”
R408-3T LIP SEAL, TEFLON 1/2”
R409-0 GLAND WASHER, TEFLON 1/8”
R409-1 GLAND WASHER, TEFLON 1/4”
R409-2 GLAND WASHER, TEFLON 3/8”
R409-3 GLAND WASHER TEFLON 1/2”
PART NO. DESCRIPTION
R412-1 ADAPTER, S.S. 1/4 NPT TO 1/4” I.D. TUBE
R412-2 ADAPTER, S.S. 1/4 NPT TO 3/8” I.D. TUBE
R412-0K ADAPTER, FLUOROCARBON 1/8” I.D. TUBE
R412-1K ADAPTER, FLUOROCARBON 1/4” I.D. TUBE
R412-2K ADAPTER, FLUOROCARBON 3/8” I.D. TUBE
R412-5K ADAPTER, FLUOROCARBON 1/4-28 THD
R412-6K ADAPTER, FLUOROCARBON 1/2” I.D. TUBE
R412-07 ADAPTER, S.S. 1/4” I.D. TUBE, SAN
R412-08 ADAPTER, S.S. 3/8” I.D. TUBE, SAN
R412-1T ADAPTER, TEFLON 1/4” I.D. TUBE, SAN
R412-2T ADAPTER, TEFLON 3/8” I.D. TUBE, SAN
R413 CYLINDER HEAD SEAL
R413-1 CYLINDER HEAD SEAL, R405-1K
R419 CYLINDER PORT SEAL, R405-S
R423-1C* PISTON
R423-2C* PISTON
R423-3C* PISTON
R423-0S PISTON
R423-1S PISTON
R423-2S PISTON
R479 LOW FLOW KIT (FITS R405-S)
R489 SPACER, SANITARY CYLINDER GROUP
R490-1 PORT SLEEVE, SANITARY CYLINDER GROUP
R520-1T ADAPTER, TEFLON 1/4” O.D. STRAIGHT, SAN
R520-2T ADAPTER, TEFLON 3/8” O.D. STRAIGHT, SAN
H476-K SML TUBE ADAPTER SET, 1/8” O.D. (OPTL)
110017-10 SCREW, SKT HD CAP 1/4-20 X 5/8”
110311
NUT, SQUARE 1/4-20
110348-P SAN PORT NUT, PLASTIC
110348-S SAN PORT NUT, STAINLESS STEEL
110384-K FERRULE NUT 1/4, KYNAR
110384-T FERRULE NUT 1/4”, TFE
110847-01 BARBED FITTING 10-32 UNC-2B 1/8” ID TUBING
200182-01
CYL CASE, SS HIGH TEMP GLAND
500074 LIP SEAL INSTALLATION TOOL,1/8”
500071 LIP SEAL INSTALLATION TOOL,1/4”
500080 LIP SEAL INSTALLATION TOOL,3/8”
500081 LIP SEAL INSTALLATION TOOL,1/2”
Please
call for Pricing
Please
call for Pricing
