FMI Q431 "Q - Manual (Page 11)

11
IN-Q431-09A
PART NO. DESCRIPTION
Q421-1 BASE ASS’Y QP
Q421-3 BASE ASS’Y QB, QD,QV, QBG
Q421-4 BASE ASS’Y QSY
Q421-5 BASE ASS’Y QSYX
Q421-6 BASE ASS’Y QG, QVG50
Q421-7 BASE ASS’Y QDX
Q424 SPINDLE ASSEMBLY QP, QDX
Q447 BUSHING, FLOW CONTROL
Q454-3 FOLLOWER
Q464 STROKE LENGTH ADJUSTMENT KNOB
Q485 DIAL INDICATOR KIT
Q616 RETAINER ASSEMBLY
Q647 BASE MOUNTING KIT
Q662 TILT STAND KIT
R424-1 SPINDLE ASSEMBLY QD, QG, QB, QV, QVG
R424-6 SPINDLE ASSEMBLY QSY, QSYX
R475 FOOT QSYX
P56C FACE MOTOR ADAPTER KIT
V109 MOTOR ASSEMBLY QV
V109G MOTOR ASSEMBLY QVG50
110049 WASHER #8 INT. LOCK
110258 FOOT, RUBBER
110262 MOTOR, QD PUMP 115V, 60Hz
110262-2 MOTOR, QD PUMP 230V , 50/60 Hz
110286-6A MOTOR, QG 6 RPM 115V, 60Hz
110286-20A MOTOR, QG 20 RPM 115V, 60 Hz
110286-50A MOTOR, QG 50 RPM 115V, 60 Hz
110286-150A MOTOR, QG 150 RPM 115V, 60 Hz
110286-400A MOTOR, QG 400 RPM 115V, 60 Hz
110290-8 SCREW, SKT HD 8-32 X 1/2”
PART NO. DESCRIPTION
110290-10 SCREW, SKT HD #8-32 X 5/8”
110290-22 SCREW, #8-32 X 1 3/8”
110297-6 DRIVE SCREW , 8-32 X 3/8”
110306-1 MOTOR, QSY 115V, 60Hz
110306-2 MOTOR, QSY 230V, 50/60Hz
110314 WASHER, #10 INT. LOCK
110336-2 MOTOR 230 VAC 50/60Hz QSYX
110337-2 RESISTOR (110336-2 230V, 50/60Hz)
110338-2 CAPACITOR (110336-2 230V, 50/60Hz)
110355-1 MOTOR, 12 VDC QB
110373 DRIVE COUPLING
110376-16 BOLT, HEX HD 3/8 -16 X 1”
110417-4
STANDOFF, HEX 8-32 X 1/4Ó FEM.
110454 CAP NUT 8-32
110471 LOCK NUT 1/4-20
110491 WASHER, FLAT 1/4” STD
110505 WASHER, SHOULDER, NYLON
110506-8 SCREW, SKT HD CAP 10-32 X 1/2”
110509 ADAPTER, PC56C
110522 MOTOR, X-PROOF QDX 115/230 VAC 60 HZ
110542-6 SCREW, HEX HD NYLON 8-32 X 3/8”
110544 SPEED KNOB
110579 WASHER, FLAT 3/8”
110580 WASHER, LOCK INT. 3/8”
110608 SPRING AND BRUSH SET, QVG50
110609 BRUSH CAP , QVG50
110671-4 SCREW, SET 8-32 X 1/4”
110837-01 SPRING BRUSH SET 12 VDC - GRAY MOTOR
110838-01 SPRING BRUSH SET 90 VDC - GRAY MOTOR
110839-01 BRUSH CAP 12, 90 VDC - GRAY MOTOR
110877 SPACER
200635 Motor + Cable ASS’Y, 1/2HP,230 VAC
Q PUMP DRIVE MODULE - PARTS PRICE LIST
PUMP DRIVE REPAIR SERVICE
Should your FMI PUMP DRIVE or SUBASSEMBLY need repairs, you should first contact the Customer
Service Department for a RETURN AUTHORIZATION NUMBER; you may then ship it to us post-paid.
You will be charged a flat service fee for each Pump Drive Module or subassembly returned plus the
cost of parts used and the postage required to return it to you.
After examining a returned pump or subassembly by FMI Service Department, you will be requested
to approve the charges before repair work is started.
PARTS ORDERS
MINIMUM ORDER APPLIES FOR DOMESTIC or FOREIGN (Invoice price exclusive of shipping)
SHIPPING
Parts and repair orders will be shipped via United Parcel Service or U.S. Postal Service unless other
means are specified.
ALL PRICES ARE QUOTED IN U.S. DOLLARS, FOB SYOSSET, NY - Subject to change without
notice.
For Additional Information Call - Toll Free 800-223-3388 or email us at: [email protected]
