B. Options

The TTP200 is programmed by selecting a pre-programmed "EIA Tone-to-Output" assignment pattern, or "Pre-Set." Pre-Sets are available for
several different output options:

1. Discrete 1 of 5 Outputs

Pre-Sets 1 through x assign the 16 standard EIA tones to activate one, and only one, of the "Fx" outputs at a time.

2. Discrete "Split" Outputs

Pre-Sets x though y split the five "Fx" outputs into two groups, one containing “ 1 of 3” outputs F1 through F3 and the other containing “1 of 2”
outputs F4 and F5.

3. Discrete "Wildcard" Outputs

Pre-Sets x though y establish outputs F1 through F4 as discrete outputs and use F5 as a "wild card" output that toggles independently of the other
outputs.

4. BCD Output

Pre-Sets x through y produce a BCD output based on the 16 EIA tones.

5. Customized Output

Once a Pre-Set has been loaded, it can be customized by manually re-programming some or all of the individual EIA Tone-to-Output
assignments. Blank Pre-Sets are provided for each of the four output types (three discrete and one binary) to facilitate building up custom EIA
Tone-to-Output assignments "from scratch."

6. Inverted Output

Leaving S2-2 (F1) ON during normal operation inverts the "Fx" outputs.

TP200 Product Description - 5/23/01 Page 11 of 28

C. Settings and Procedures

1. S2 Setting -- Normal Operation:

OFF

PROG

2. S2 Setting -- Inverted Outputs:

OFF

PROG
