D. Pre-Set EIA Tone-to-Output Assignments
Discrete 1 of 5 Outputs - when an assigned EIA Tone is received, its output is turned ON and all other outputs are turned OFF:
Pre-Set Number LED indication
1
A = on !
B = off #
C = off #
D = off #
Output Line EIA Tone
F1 1950
F2 1850
F3 1350
F4 1250
F5 1150
Pre-Set Number LED indication
2
A = off #
B = on !
C = off #
D = off #
Output Line EIA Tone
F1 1950
F2 1850
F3 1350
F4 1250
F5 not assigned
TP200 Product Description - 5/23/01 Page 18 of 28
Discrete Split Outputs - Outputs are split into two groups. When an assigned EIA Tone in either group , its output is turned ON and all other
outputs in that group are turned OFF:
Pre-Set Number LED indication
5
A = on !
B = off #
C = on !
D = off #
Output Line EIA Tone
F1 - group a 1950
F2 - group a 1850
F3 - group a not assigned
F4 - group b 1450
F5 - group b 1550
Pre-Set Number LED indication
6
A = off #
B = on !
C = on !
D = off #
Output Line EIA Tone
F1 - group a 1950
F2 - group a 1850
F3 - group a 1750
F4 - group b 550
F5 - group b 450
Pre-Set Number LED indication
3
A = on !
B = on !
C = off #
D = off #
Output Line EIA Tone
F1 1950
F2 1850
F3 1750
F4 1650
F5 1550
Blank Pre-Set #4 is provided to facilitate building up a Discrete 1 of 5 Output set “from scratch”:
Pre-Set Number LED indication
4
A = off #
B = off #
C = on !
D = off #
Output Line EIA Tone
F1 not assigned
F2 not assigned
F3 not assigned
F4 not assigned
F5 not assigned
