Binary Four-Bit Outputs:
Pre-Set Number LED indication
11
A = on !
B = on !
C = off #
D = on !
Output Lines
F1 F2 F3 F4 F5
EIA Tone
0 0 0 0 0 1950
1 0 0 0 0 1850
0 1 0 0 0 1750
1 1 0 0 0 1650
0 0 1 0 0 1550
1 0 1 0 0 1450
0 1 1 0 0 1350
1 1 1 0 0 1250
0 0 0 1 0 1150
1 0 0 1 0 1050
0 1 0 1 0 950
1 1 0 1 0 850
0 0 1 1 0 750
1 0 1 1 0 650
0 1 1 1 0 550
1 1 1 1 0 450
Pre-Set Number LED indication
12
A = off #
B = off #
C = on !
D = on !
Output Lines
F1 F2 F3 F4 F5
EIA Tone
1 0 0 0 0 1950
0 1 0 0 0 1850
1 1 0 0 0 1350
0 0 1 0 0 1250
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
0 0 0 0 0 n/a
