I. Connectors
connector location function
J1 front panel connects to local mic when modular interconnection configuration is used
J2 front panel connects to radio when modular interconnection configuration is used
J3 back panel connects to remotes
J4 board, rear
auxiliary 2-wire or 4-wire RX connection to remotes
auxiliary 12 Volt D.C. supply connection
J5 board, rear auxiliary 4-wire TX connection to remotes
J6, J7 board, front
connects to radio and local mic when hand-wired interconnection configuration is
used
II. Connector Pinouts
pin function
J1-1 n.c.
J1-2 n.c.
J1-3 Local Mic PTT output
J1-4 Local Mic Audio output
J1-5 ground
J1-6 Local Mic Monitor output
J1-7 n.c.
J1-8 n.c.
TP200 Product Description - 5/23/01 Page 2 of 28
pin function
J2-1 Radio RX Audio output
J2-2 n.c.
J2-3 Radio PTT input
J2-4 Radio TX Modulation input
J2-5 ground
J2-6 Radio Monitor input
J2-7 Radio F1/F2 input
J2-8 n.c.
pin function
J3-1 n.c.
J3-2 4-Wire TX
J3-3 2-Wire; 4-Wire RX
J3-4 2-Wire; 4-Wire RX
J3-5 4-Wire TX
J3-6 n.c.
pin function
J4-1 power supply ground
J4-2 +12 Volts D.C. input
J4-3 2-Wire; 4-Wire RX
J4-4 2-Wire; 4-Wire RX
pin function
J5-1 4-Wire TX
J5-2 n.c.
J5-3 4-Wire TX
TP200 Product Description - 5/23/01 Page 3 of 28
pin function
J6-1 +12 Volts D.C. input
J6-2 power supply ground
J6-3 PTT output
J6-4 RX Audio input
J6-5 Monitor relay output common
J6-6 Monitor relay output normally open
J6-7 Monitor relay output normally closed
J6-8 TX Modulation output
J6-9 Local Mic Audio input
J6-10 Squelch Control input
pin function
J7-1 +12 Volts D.C. input
J7-2 power supply ground
J7-3 F1/F2 relay output common
J7-4 F1/F2 relay output normally open
J7-5 F1/F2 relay output normally closed
J7-6 F1 open-collector output
J7-7 F2 open-collector output
J7-8 F3 open-collector output
J7-9 F4 open-collector output
J7-10 F5 open-collector output
