1. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the specified operating conditions.
• Typical characteristics and specifications are measured at nominal supply voltages and T
A
= 25°C.
• VLR = 0 V. All voltages measured with respect to 0 V.
ANALOG CHARACTERISTICS
T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- = V2- = -2.5 V,
±5%; VL -VLR = 3.3 V, ±5%; VREF = (VREF+) - (VREF-) = 4.096V; MCLK = 16 MHz; SMODE = VL. DITHER = VL
unless otherwise stated; BUFEN = V1+ unless otherwise stated. Connected per
Figure 6 . Bipolar mode unless oth-
erwise stated.
1. No missing codes is guaranteed at 16 bits resolution over the specified temperature range.
2. One LSB is equivalent to VREF ÷ 2 16 or 4.096 ÷ 65536 = 62.5 µV.
3. Total drift over specified temperature range after reset at power-up, at 25º C.
4. With DITHER off the output will be dominated by quantization.
5. Scales with MCLK.
Parameter Min Typ Max Unit
Accuracy
Linearity Error - 0.0008 -
±%FS
Differential Linearity Error (Note 1) - - ±0.1 LSB
16
Positive Full-scale Error - 1.0 - %FS
Negative Full-scale Error - 1.0 - %FS
Full-scale Drift (Note 2, 3) - ±1 - LSB
16
Bipolar Offset (Note 2) - ±15 - LSB
16
Bipolar Offset Drift (Note 2, 3) - ±1 - LSB
16
Noise (Note 4) - 36 -
µVrms
Dynamic Performance
Peak Harmonic or Spurious Noise 1 kHz, -0.5 dB Input
12 kHz, -0.5 dB Input
-
- -96
-96 -
- dB
dB
Total Harmonic Distortion 1 kHz, -0.5 dB Input - -94 -82 dB
Signal-to-Noise 91 92 - dB
S/(N + D) Ratio -0.5 dB Input, 1 kHz
-60 dB Input, 1 kHz
-
- 91
32 -
- dB
dB
-3 dB Input Bandwidth (Note 5) - 84 - kHz
