CRD5463PM
2 DS805RD2
1. CHARACTERISTICS AND SPECIFICATIONS
1.1 Recommended Operating Conditions
1.2 Electrical Characteristics
NOTES:
1. Measured at VAC = 240 V and T
A
= 25º C.
2. Measured at T
A
= 25º C and PF=1.
WARNING
High Voltage Hazard
When the CRD5463PM is connected to AC lines, high voltage is present inside the box.
DO NOT REMOVE THE PROTECTIVE COVER FROM THE CRD5463PM WHEN POWER IS CONNECTED.
Figure 1. Calibration and Test Connection Diagram
NOTES:
1. Voltage drop and power loss in the cable connecting the CRD5463PM and the reference meter may introduce
additional error.
2. The measurement bandwidth of the CS5463 is 2 kHz. At low power factor, the CRD5463PM may measure lower
current and higher power factor than the reference meter if the reference meter has a measurement bandwidth
greater than 2 kHz.
3. When testing at low power factor, the peak load current shall never exceed 22 A.
Parameter Symbol Min Typ Max Unit
Voltage Range V
AC
90 - 260 V
Current Range
RMS Current I
rms
- - 15 A
Peak Current I
peak
- - 22 A
Frequency Range Freq 5 2000 Hz
Operating Tempereture T
A
-40 - +85 ºC
Parameter Symbol Min Typ Max Unit
Power Consumption (Note 1)
Current Consumption
Power Consumption
I
AC
- 79 - mA
P
AC
- 2.3 - W
Accuracy (Note 2)
RMS Voltage Measurement (90 ~ 260 VAC)
RMS Current Measurement (30 mA ~ 15 A)
Active Power Measurement (3 W ~ 3900 W)
V
accu
- ±0.1 - %
I
accu
- ±0.2 - %
P
accu
- ±0.2 - %
Measurement Bandwidth BW - - 2 kHz
CRD5463PM
AC
SOURCE
AC
Load
GUI
USB
Reference
Meter
(V, A)
