DS565F2 5
CS5351
ANALOG CHARACTERISTICS (CS5351-KSZ/KZZ)
(Test conditions (unless otherwise specified): Input test signal is a 1 kHz sine wave; measurement bandwidth is
10 Hz to 20 kHz.)
Notes: 4. Referred to the typical full-scale input voltage.
Parameter Symbol Min Typ Max Unit
Single-Speed Mode Fs = 48 kHz
Dynamic Range
A-weighted
unweighted
102
99
108
105 -
- dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
THD+N
-
-
- -98
-84
-44 -92
-
-
dB
dB
dB
Double-Speed Mode Fs = 96 kHz
Dynamic Range
A-weighted
unweighted
40 kHz bandwidth unweighted
102
99
-
108
105
102 -
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -98
-84
-44
-95 -92
-
-
-
dB
dB
dB
dB
Quad-Speed Mode Fs = 192 kHz
Dynamic Range
A-weighted
unweighted
40 kHz bandwidth unweighted
102
99
-
108
105
102 -
-
- dB
dB
dB
Total Harmonic Distortion + Noise (Note 4)
-1 dB
-20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N
-
-
-
- -98
-84
-44
-95 -92
-
-
-
dB
dB
dB
dB
Dynamic Performance for All Modes
Interchannel Isolation - 95 - dB
DC Accuracy
Interchannel Gain Mismatch - 0.1 - dB
Gain Error -2 - 2 %
Gain Drift -100 - 100 ppm/°C
Offset Error HPF enabled
HPF disabled
-
- -
- 0
100
LSB
LSB
Analog Input Characteristics
Full-scale Input Voltage 0.55*VA 0.56*VA .57*VA Vpp
Input Impedance 7.5 - - k Ω
Common Mode Rejection Ratio CMRR - 82 - dB
