1. INTRODUCTION
The CS5333 and CS5343/4 are complete stereo analog-to-digital converters for digital audio systems. These con-
verters perform sampling, analog-to-digital conversion and anti-alias filtering, generating 24-bit values for both left
and right channels. These small, low-power converters are ideal for systems requiring wide dynamic range and low
noise such as set-top boxes, A/V receivers, DVD-karaoke players, DVD recorders, and automotive applications.
The CS5333 is no longer recommended for new designs, and the CS5343/4 is the suggested replacement.
This application note identifies the implementation differences between these two devices, including:
•
Key specifications
•
Pinout differences
•
Startup mode selections
•
System clocking
•
Input filter topology
•
Reference voltage
The CS5333 and CS5343/4 datasheets contain detailed information regarding device specifications, performance
and ordering information. Please reference the CS5333 and CS5343/4 datasheets while reading this document.
2. KEY SPECIFICATIONS
shows a comparison of the key specifications of these two device families, and
parison between the CS5333 and the CS5343/4. Although these two devices are not pin compatible, they are very
similar in terms of overall functionality and feature set.
Parameter
CS5333
CS5343/4
Units
Conversion
24
24
Bits
Dynamic Range (A-Weighted)
98
98
dB
THD+N
-88
-90
dB
Analog Core Power Supply (VA)
+1.8 to +3.3
+3.3 to 5
V
Digital Core Power Supply (VD)
Powered from VA
Powered from VA
V
Digital Interface Power Supply (VL)
+1.8 to +3.3
Powered from VA
V
Typical Power ConsumptionAll supplies = +3.3 V
36
50
mW
Maximum Sample Rate
100
108
kHz
Package
16-pin TSSOP
10-pin TSSOP
Table 1. Comparison of Key Specifications
