AN298
RC1
4
8
Virtualizer-Processor Overlay:
(Continued)
SRS TruSurround XT ®
(AN298VPMH)
V01 0xBA00HHHH 0xhhhhhhhh 0xBAC0HHHH 0x3AC0HHHH 0xhhhhhhhh
Dolby Headphone 2
(AN298VPMK) V01 0xC000HHHH 0xhhhhhhhh 0xC0C0HHHH 0x40C0HHHH 0xhhhhhhhh
Dolby Virtual Speaker 2
(AN298VPML) V01 0xC100HHHH 0xhhhhhhhh 0xC1C0HHHH 0x41C0HHHH 0xhhhhhhhh
SRS® TruSurround HD4™ Modules
(with WOW HD (AN298VPMM) V04, V09 0xB300HHHH 0xhhhhhhhh 0xB3C0HHHH 0x33C0HHHH 0xhhhhhhhh
Cirrus Virtualization Technology
(CVT) - Virtualizer Processor Module
(AN298VPMN) V05 0xC100HHHH 0xhhhhhhhh 0xC1C0HHHH 0x41C0HHHH 0xhhhhhhhh
Post Processing Overlays:
Audio Manager
(AN298) All 2 0x8300HHHH 0xhhhhhhhh 0x83c0HHHH 0x03c0HHHH 0xhhhhhhhh
PCM Manager
(AN298) Al l2 0x9B00HHHH 0xhhhhhhhh 0x9BC0HHHH 0x1BC0HHHH 0xhhhhhhhh
Delay
(AN298PPMA) All l2 0xD900HHHH 0xhhhhhhhh 0xD9C0HHHH 0x59C0HHHH 0xhhhhhhhh
Bass Manager
(AN298PPMB) All l2 0xD700HHHH 0xhhhhhhhh 0xD7C0HHHH 0x57C0HHHH 0xhhhhhhhh
Cirrus Band XpandeR (BXR)
(AN298PPMC) All l2 0xE700HHHH 0xhhhhhhhh 0xE7C0HHHH 0x67C0HHHH 0xhhhhhhhh
Cirrus Dynamic Volume Leveler (DVL)
(AN298PPMD) All l2 0xE600HHHH 0xhhhhhhhh 0xE6C0HHHH 0x67C0HHHH 0xhhhhhhhh
EQ Module with PEQ and Direct
Coefficient Mode (11-bands)
(AN298PPME) All l2 0xD500HHHH 0xhhhhhhhh 0xD5C0HHHH 0x55C0HHHH 0xhhhhhhhh
Tone Control
(AN298PPMF) All l2 0xD400HHHH 0xhhhhhhhh 0xD4C0HHHH 0x54C0HHHH 0xhhhhhhhh
Dolby Volume
AN298PPMN V03 0xE000HHHH 0xhhhhhhhh 0xE0C0HHHH 0x60C0HHHH 0xhhhhhhhh
Table 2-1. Firmware Module Read and Write Addresses with Associated Application Note Reference (Cont.)
DSP Firmware Module /
(Application Note Name)
Firmware Version/Memory Map(s)
Supported
Write Request Read Request Read Response
