CS4396
DS288PP1
7
DIGITAL CHARACTERISTICS
(T
A
= 25°C; VD = 3.0V - 5.25V)
ABSOLUTE MAXIMUM RATINGS
(AGND = 0 V, all voltages with respect to ground.)
WARNING: Operation at or beyond these limits may result in permanent damage to the device. Normal operation
is not guaranteed at these extremes.
RECOMMENDED OPERATING CONDITIONS
(DGND = 0V; all voltages with respect to ground)
Parameters
Symbol Min Typ
Max
Units
High-Level Input Voltage
VD = 5 V
VD = 3 V
V
IH
2.0
2.0
-
-
-
-
V
V
Low-Level Input Voltage
VD = 5 V
VD = 3 V
V
IL
-
-
-
-
0.8
0.8
V
V
Input Leakage Current
I
in
-
-
±10
µ
A
Input Capacitance
-
8
-
pF
Maximum MUTEC Drive Current
-
3
-
mA
Parameter
Symbol Min
Max
Unit
DC Power Supply: Positive Analog
Positive Digital
Reference Voltage
VA
VD
VREF
-0.3
-0.3
-0.3
6.0
6.0
VA
V
V
V
Input Current, Any Pin Except Supplies
I
in
-
±10
mA
Digital Input Voltage
V
IND
-0.3
(VD)+0.4
V
Ambient Operating Temperature (power applied)
T
A
-55
125
°C
Storage Temperature
T
stg
-65
150
°C
Parameter
Symbol Min Typ
Max
Unit
DC Power Supply: Positive Digital
Positive Analog
Reference Voltage
VD
VA
VREF
3.0
4.75
TBD
3.3
5.0
5.0
5.25
5.25
VA
V
V
V
Specified Temperature Range
T
A
-10
-
70
°C
